Overview

The SVAD‑ST diffuser is a 24 in. (600 mm) square ceiling‑mounted VAV diffuser equipped with a built‑in electric motor and DDC controller. Integrated temperature sensors enable both VAV cooling and VAV heating functions. Four blade dampers modulate airflow—opening and closing to deliver warm or cool air into the room in direct response to temperature conditions.

Room air is positively induced across the built‑in temperature sensor, or alternatively measured via a wall‑mounted thermostat, external sensor, or desktop remote sensor. This ensures accurate and responsive room temperature control in both cooling and heating modes.

Optional Equipment and Accessories

• Remote control for user convenience

• Electric heater for reheating supply airflow in perimeter zones

• Propeller blade airflow sensor for precise airflow measurement

• CO₂ sensor for indoor air quality monitoring and demand‑controlled ventilation

• Relative humidity (RH) sensor for room humidity monitoring and control

Features

- APP Control

- Modbus RTU protocol

- Quiet motorized control

- Individual comfort over a wide range of control

- Bladed damper design provides high discharge air velocity over full operating range

- 2-year warranty

- Size: 06, 08, 10, 12
